SmartSteering

SES is for geologists who are dissatisfied with drafting or gridding-tool methods of geosteering. SES is 3D technical geosteering software that makes wellbore stratigraphic tracking quick-n-easy, accurate, and easily shared. Unlike any other geosteering software, SES provides a complete suite of software features to handle all of your horizontal drilling needs.



SES is horizontal and directional well bore drilling software...from pre-spud well planning with geologic model data integration through landing and 3D technical geosteering / stratigraphic interpretation while drilling or post drilling. Includes the 3DStratBlock  technical geosteering method with Relative Stratigraphic Depth (RSD) signal mapping, traditional 3D/2D well planning, survey calcs, Technical Hole Deviation (THD) calcs, THD logs, steering guidance from patented Fuzzy Logic control technology, and advanced visual geosteering interpretation tools using LWD (gamma ray, resistivity, etc.) and other data.



SES FEATURE HIGHLIGHTS



FreeFREE Feature Option

FREE BASIC G G&G
infoExtreme data loading and updating ease check check check check
infoCompute directional survey with 2D and 3D graphing check check check check
infoInterpolate survey for Cartesian coordinates at any MD check check check check
infoCompute 3D directional well plan with unlimited targets check check check check

infoVertical section azimuth set by individual survey or plan

check check check check
infoSimultaneous multi-user access to database on network drive check check check check
infoRun multiple instances independently from one computer check check check check
infoEasily transfer data between SES users or databases check check check check
infoEasily transfer data to other O&G software applications check check check check
Create directional survey or plan report for regulatory filing check check check check

USA & metric units supported

check check check check

BasicBASIC Feature Option

FREE BASIC G G&G

Compute Technical Hole Deviation (THD)

  check check check

Create THD Logs with vertical section and plan views

  check check check
infoView geologic model from 3D grid/seismic data interpolation   check check check
infoMultiple license formats supported   check check check

GeosteeringGEOSTEERING Feature Option ("G")

FREE BASIC G G&G
infoIndustry's most advanced 3D Technical Geosteering logic     check check
infoHuge assortment of features to enhance interpretation quality     check check
infoUse multiple type logs to communicate thickness variations     check check
infoCreate interpretation gaps/overlaps while actively geosteering     check check
infoGraph up to 8 LWD data curves while actively geosteering     check check
infoEasily create a "derived" type log from interpretation portions     check check
infoSmooth noisy LWD data on the fly while still displaying raw data     check check
infoRescale type log and/or LWD data on the fly     check check
infoEasily manage multiple working hypotheses/interpretations     check check
infoGenerate detailed/annotated TVD vs. MD|VS cross-sections     check check
infoDisplay well paths, payzone, and multiple tracks of LWD data     check check
infoDisplay multiple offset layers for enhanced visualization     check check
infoDisplay interpolated 3D grid data along wellbore & ahead of bit     check check
infoPost center-line & parallels for new planned well path for ops     check check
infoCalculate & post current footage and percent-in-zone stats     check check
infoExport layer properties/coordinates to revise 3rd-party software     check check
infoDisplay and size inset map view of survey(s) & plan     check check
infoDisplay and size inset RSD track of interpretation     check check
infoSize main cross-section graph width and set paper size     check check
infoDisplay one custom image/logo     check check

Guidance and GeosteeringGUIDANCE & GEOSTEERING Feature Option ("G&G")

FREE BASIC G G&G
infoDisplay up to four custom images/logos on cross-sections       check
infoGenerate and display image logs from 8-sector Azimuthal data       check

image log

SES-generated Azimuthal gamma ray image log from 8-sector data

Enlarge
infoRT data loading/updating via WITSML server import via internet       check
infoReceive steering guidance from Fuzzy Logic control technology       check
infoGuidance calc'd with target TVD|Inc from geosteering interp       check



SES-COMPATIBLE WITSML SERVERS



SES has successfully downloaded directional survey data (MD/Inc/Azi) and downloaded/quantized logging data (e.g., real-time gamma ray, ROP, etc.) from the WITSML servers listed below. There are likely numerous other WITSML servers that are equally SES-compatible, due to the intent and purpose of WITSML standards.



Company WITSML Server URL snip Date NOTES
Baker Hughes https://witsml.bakerhughesdirect.com 2012-05 none
Canrig Drilling Technology https://witsml.mywells.com 2012-04 1
National Oilwell Varco https://witsml.welldata.net 2012-04 1
Pason https://hub.pason.com 2012-05 none
Perfomix http://witsml.perfomix.net 2012-04 none
PetroDAQ https://secure.petrodaq.com 2012-04 none
Polaris Guidance Systems http://witsml.polarisguidance.com 2013-12 none
Shell/Halliburton https://witsml.americas.shell.com 2012-02 none
Contact us to get listed here after testing



NOTES regarding server-specific access configuration settings within SES (UTILITIES screen, WITSML Server tab, Configure Server):



   1 - check "Assume uidWellbore=uidWell"



SES - STONER ENGINEERING SOFTWARE



SES is practical oil & gas drilling software with advanced yet easy-to-use tools to determine:

  • WHERE your horizontal wellbore is stratigraphically located, AND (if used while drilling)

  • HOW to steer through or to your payzone

Geologic earth models are great for horizontal well planning (and easily entered from grid data and viewed in SES), but, for real-time operations, constant and intelligent interpretation of virgin data is critical to maximize effective payzone penetration at minimal cost. Interpretation of the new data subsequently refines the geologic earth model.



SES Technical Geosteering provides an estimate of the payzone formation location in 3D space over the drilled horizontal wellbore. The location and frequency of faults may also be identified, which can have multiple impacts on future development and remediation activities.



SES exploits cutting-edge FRIENDLY database technology to produce an experience like no other, with respect to directional steering data management, visualization, navigation, monitoring, and geologic interpretation.



With Technical Hole Deviation (THD) Technology, SES provides unsurpassed mathematical incorporation of real-time directional well planning and surveying for most-informed directional steering monitoring and decision making.



The odds--of knowing where the payzone is, while drilling or post-drilling--are maximized with SES. SES is industry's most advanced fully integrated directional planning and execution 3D technical geosteering software available and the only software that operates with 3DStratBlocks and RSD (Relative Stratigraphic Depth) signal mapping, and THD Technology. It's also the only related software that eliminates distortion (from vertical section projection) by going 3D!



But, if you only need general 3D directional well planning and surveying capabilities without THD, grid data integration, technical geosteering, or steering guidance, it is totally FREE.






Friendly

Drilling

Software



FDS is rig site software for drilling data capture/storage and daily reporting. Data entry is quick-and-easy and reports are graphical. And, it's totally FREE!



SELECT FDS FEATURE HIGHLIGHTS



30-day instant free trial without registration; then registration & use are totally FREE.
QUICK-AND-EASY data entry. Intelligent defaults designed to save you time.
Highly integrated storage of: Time, Footage, Drilling Parameters, Bits, BHAs, Directional Surveys, Mud-Checks, Weight/Torque, Casing, Lithology/Gas, and Cost Data.
The simplest-ever IADC dull bit grading for steel tooth, insert, and fixed cutter bits.
2-Page (Letter or A4) visually-pleasant Daily Drilling Summary. Pg 1 includes an annotated Time vs. Depth plot with actual, planned, and highlighted last-24-hours. Pg 2 includes snapshot directional section and plan view plots, TO SCALE.
Revised Time Categories and Time Sub-Categories, and the option to mark time log entries as "UNPLANNED".
COMPLETE UNITS FLEXIBILITY. Source units do not have to equal report units! Independent input/output units for Long Length, Short Length, Force, Torque, Pressure, Flowrate, Area, Density, Velocity, Hydraulic Horsepower, and Temperature.
Via intelligent integration of the data, pressure losses, hydraulics, and annular velocities are automatically computed and reported.
Create various end-of-well data summaries.
Create a Daily Drilling Summary (DDS) file. The small DDS file contains all data for the daily report. Send the DDS file to others and they can re-create the entire report on their computer; a very nice feature when working in a remote, low-bandwidth area.
Create a flat file that contains the entire information for a particular well. This FDS Well File can be exported and imported by FDS.



FDS - FRIENDLY DRILLING SOFTWARE



FDS is a database program designed to capture and store pertinent drilling information at the source, i.e., the rig. FDS was developed in 1998 and field-tested by professionals experienced in drilling operations, drilling engineering, and database development.



FDS comes with an instant free trial period of 30 days before FREE registration is required for continued use. Simply download and use it. If you like it, then register. However, FDS is no longer supported/developed.



The current (and only) version of FDS is 1.1.  (2003-11-17)



Click here for screen captures of FDS.
